Automatic Organic Wastewater Purification System with Subsequent Filtration
All equipment can be fully customized to meet your specific requirements. Please share your technical parameters, flow charts, or other demands. We guarantee a quick response within 12 hours via email or online chat.
| Model | Water Yield (T/H) | Inlet Pipe (Dg1/mm) | Outlet Pipe (Dg2/mm) | Drain Pipe (Dg3/mm) | Equipment Dimensions (mm) | Weight (T) |
|---|---|---|---|---|---|---|
| DLB 20-11 | 20 | Φ100 | Φ100 | Φ300 | 1400×900×1134 | 21.9 |
| DLB 40-11 | 40 | Φ150 | Φ150 | Φ360 | 1800×1000×1350 | 35.7 |
| DLB 60-11 | 60 | Φ200 | Φ150 | Φ460 | 2240×1000×1540 | 50.6 |
| DLB 80-11 | 80 | Φ200 | Φ200 | Φ460 | 2460×1000×1636 | 65.7 |
Additional Specifications:
Inlet/Outlet Takeover Height (H1/H2): 4710–4810 mm
Drainage Takeover Height (H3): 400–500 mm
Foundation Requirements: Flexible asphalt sand base
This gravity valveless filtration system requires only basic foundation preparation and connection of inlet/outlet pipes to begin operation. Designed with a sealed top cover, it meets stringent hygiene standards and can be installed outdoors. Compared to traditional reinforced concrete filters, it offers a lighter weight, simpler installation, and reduced maintenance needs.
Initial Operation:
When the filter starts, the media layer is clean, ensuring optimal flow and low head loss.
Filtration Cycle:
As suspended solids accumulate in the filter media, head loss gradually increases.
Water levels in the siphon riser tube rise slowly due to increased resistance.
Automatic Backwashing:
When head loss reaches a critical point, water overflows into the siphon auxiliary tube.
The rapid flow creates a vacuum effect, initiating a siphoning action that draws water over the siphon crest.
This triggers a full automatic backflush, cleaning the filter media without manual intervention.
After backwashing, the system resumes normal operation.
This system is ideal for:
Surface water purification (rivers, lakes, reservoirs).
Groundwater iron and manganese removal.
Industrial circulating water side-stream filtration.
Suspended solids removal in production wastewater.
Post-treatment filtration for organic wastewater after biochemical/activated sludge processes.
Secondary filtration after sedimentation tanks.
Indoor swimming pool water recycling.
Fully Automatic Operation: No manual controls needed for backwashing.
Hygienic Design: Sealed cover prevents contamination and allows outdoor installation.
Adaptability: Handles varying organic loads and suspended solids concentrations.
Low Operating Costs: Energy-efficient backwashing mechanism.
Compact & Modular: Saves space compared to conventional concrete filters.
